Panchal Engineering Works

List of Machineries and Equipments in our workshop

• 1. Horizontal Boring Machine (Heavy Duty) with DRO system. 1 No.
  • Make : TOS (Germany)
  • Capacity :
  • » Spindle size: 100 mm dia.
  • » Cross traveling : 1.8mtr.
  • » Longitudinal traveling : 3mtr.
• 2. Horizontal Boring Machine with DRO system. 1 No.
  • Make : KARAM
  • Capacity :
  • » Spindle size: 100 mm dia.
  • » Cross traveling : 1.5mtr.
  • » Longitudinal traveling : 3mtr.
• 3. Universal Milling Machine with DRO system. 1 No.
  • Make : CINCINNATI (USA)
  • Capacity :
  • » Spindle : ISO 50
  • » Cross traveling : 600mm.
  • » Longitudinal traveling : 1.5mtr.
• 4. Vertical Milling Machine with DRO system. 1 No.
  • Make : TOS (Germany)
  • Capacity :
  • » Spindle : ISO 50.
  • » Cross traveling : 0.5mtr.
  • » Longitudinal traveling : 1mtr.
• 5. Milling with Slotting machine. 1 No.
  • Make : HOLKE (USA)
  • Capacity :
  • » Spindle : ISO 40.
  • » Cross traveling : 400mm.
  • » Longitudinal traveling : 1mtr.
• 6. VTL (VERTICAL TURRET LATHE MACHINE). 1 No.
  • M-49 Nites 42 IN
  • 40.4 Jaw Chuck / Table.
  • 5 Position Turret.
  • Side Head – 36".
  • Under Rail – 50” swing W/side Head down.
• 7. Hydraulic press operated vertically. 1 No.
  • » Machine capacity : 500 tones.
  • » Job capacity : 1.2mtr. Length.
• 8. Hydraulic press operated horizontal. 1 No.
  • » Machine capacity : 200 tones.
  • » Job capacity : 3.5mtr. length X 1.5mtr. dia.
• 9. Hydraulic press operated vertically. 1 No.
  • » Machine capacity : 50 tones.
  • » Job capacity : 3.5mtr. length X 0.5mtr. dia.
• 10. Plate bending machine having capacity to bend 30mm plate with 2 mtr. length. 1 No.
• 11. Heavy duty planning machine having table length 12 ft. x 1.2mtr. width with Plano miller attachment. 1 No.
• 12. Heavy duty Lathe machine having 24 ft. length and center distance 22". 1 No.
  • Gap distance 32".
  • Capacity :
  • » Job carrying capacity : 5’ dia.
  • » In gap carrying capacity : 10’ dia.
• 13. Heavy duty lathe machine having 22 ft. length and center distance 32”. 1 No.
  • Gap distance 45".
  • » Job carrying capacity : 5’ dia./li>
  • » In gap carrying capacity : 10’ dia.
• 14. VERTICAL PILLER DRILL MACHINE. 1 No.
  • MEUSER CO : Germany (Fully Automatic) Max.
  • Drilling Capacity : 300mm.
• 15. Heavy Lathe machine 18 ft. length. 2 Nos.
• 16. Lathe machine 16 ft. length. 2 Nos.
• 17. Lathe machine 10 ft. length. 3 Nos.
• 18. Lathe machine 9 ft. length. 8 Nos.
• 19. Lathe machine 6 ft. length. 2 Nos.
• 20. Heavy duty shaping machine having 32” stroke. 1 No.
• 21. Argon Welding machine. 1 No.
• 22. Welding machine with all necessary accessories. 3 Nos.
• 23. Plasma cutting Machine. 1 No.
• 24. Gas cutting equipments with all necessary accessories. 3 Set.
• 25. Radial drill machine. 2 Nos.
• 26. Pillar Drill machine. 1 No.
• 27. Vertical drill machine. 3 Nos.
• 28. Hacksaw machine. 2 Nos.
• 29. Slotting machine having stroke 2 ft. x 5 ft. dia. 1 No.
• 30. Portable grinder machine. 6 Nos.
• 31. Portable dril machine with magnetic attachment. 1 No.
• 32. Portable drill machine. 2 Nos.
• 33. All the standard measuring equipment like Vernier, Dial vernier, Dial guage, Micro meters
  inside Micro meter, outside Micro meter etc. 1 No.
• 34. The workshop is equipped with movable overhead crane having capacity 7 tones.
• 35. Extra chain pulley block having capacity from 1 ton to 10 tones. 3 No.
• 36. The designing & R&D office is equipped with computer having Autocad for Engineering drawing with Plotter facility.
  The computer office is equipped with all communication facility like Email, Internet,
  Fax and Phones facility with computerized corresponding and Accounting system. 8 No.
• 37. Fully trained staff Engineers and Employees.
